Repligen Process Reservoir 3 Dip Tubes 50 mL Conical Bottom ACBT-050-C1N

Description

Repligen ACBT-050-C1N 50 ml Conical Bottom Reservoir (3 Dip Tubes)

The Repligen ACBT-050-C1N is a high-performance 50 ml conical bottom reservoir engineered for critical fluid management in biopharmaceutical and laboratory research applications. This specialized vessel features a factory-integrated cap assembly with three distinct dip tubes, enabling multiple fluid paths for simultaneous aspiration, recirculation, and addition within a closed system. The conical bottom geometry is specifically designed to minimize dead volume, ensuring maximum recovery of high-value biological samples. Delivered individually sealed and ready for integration into aseptic workflows, the ACBT-050-C1N is a premier solution for researchers performing small-scale perfusion, tangential flow filtration (TFF), and automated liquid handling where process integrity and minimal hold-up volume are essential.

Technical Performance and Design

• Triple Dip-Tube Configuration: Features three precision-positioned dip tubes that extend to the base of the conical well, allowing for complex fluid routing such as simultaneous inlet/outlet and pH or nutrient sensing.

• High-Recovery Conical Geometry: The steep-walled conical base concentrates the liquid at the lowest point, facilitating nearly complete sample aspiration and reducing precious reagent waste.

• Closed-System Integrity: Designed to maintain a sterile barrier while allowing for consistent liquid transfer, significantly reducing the risk of environmental contamination during sensitive bioprocesses.

• Individually Sealed Packaging: Each unit is individually wrapped and sealed to maintain cleanliness and ensure that the component is ready for immediate use in controlled laboratory environments.

Product Specifications

• Catalog Number: ACBT-050-C1N

• Reservoir Volume: 50 ml

• Vessel Geometry: Conical Bottom

• Port Configuration: 3 Dip Tubes (Integrated into cap assembly)

• Material: High-purity, medical-grade polymers (USP Class VI compliant)

• Packaging: Individually sealed units

• Compatibility: Optimized for use with Repligen KrosFlo and other benchtop TFF or perfusion systems.

Key Benefits & Applications

• Tangential Flow Filtration (TFF): Acts as a centralized feed and recirculation reservoir for small-scale concentration and diafiltration of proteins or viral vectors.

• Small-Scale Perfusion: Ideal for use as a media addition or waste removal vessel in continuous cell culture setups.

• Automated Sampling: The multi-port design allows for a dedicated line for automated samplers while other lines maintain the primary fluid loop.

• Sterile Fluid Transfer: Provides a robust, leak-proof container for the aseptic movement of biological intermediates between workstations.
